S8-W-4
Plug-in connector angle
Series S
- Plug-in connector for flexible fabrication on-site
Technical Data
| Fixing thread | M8 |
| Connection type | Solder connection |
| Connection type | Solder connection |
| Version | Angle |
| No. of contacts | 4 |
| Rated voltage | 30 [V] |
| Current load (at 40°C) | 4 [A] |
| Insulation resistance | ≥108Ω |
| Resistance | ≤3 mΩ |
| Contact material | Metal, CuZn, gold-plated |
| Contact-carrier material | Plastic, PA, BK |
| Grip body material | Plastic, PBT/PA, BK |
| Approvals | LABS / REACH / RoHS |
| Protection to IEC 60529 | IP67 |
