Vacuum ejector
Series ZPS
- High-performance
- Volume flow: 171 l/min–175 l/min
- Air consumption: 197 l/min–350 l/min
- Max. vacuum level: -87 kPa
- Outstanding for the food industry
The solution is ideal for applications with high volume flow requirements and low vacuum levels. This allows sensitive workpieces to be handled with little pressure.
Vacuum level max.
Silencer
Volume flow [l/min]
Weight [kg]
Installation size: ZPS10 | ||||
| Order-No. | Max. vacuum level | Volume flow | Air consumption at 4 bar | |
|---|---|---|---|---|
| ZPS10-1B20-A-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B20-A-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B20-A-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B20-SS-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B20-SS-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B20-SS-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B40-A-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B40-A-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B40-A-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B40-SS-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B40-SS-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-1B40-SS-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B20-A-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B20-A-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B20-A-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B20-SS-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B20-SS-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B20-SS-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B40-A-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B40-A-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B40-A-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B40-SS-H12 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B40-SS-H19 | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
| ZPS10-2B40-SS-S | -35 [kPa] | 175 [l/min] | 197 [l/min] | |
Installation size: ZPS20 | ||||
| Order-No. | Max. vacuum level | Volume flow | Air consumption at 4 bar | |
| ZPS20-1B20-A-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B20-A-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B20-A-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B20-SS-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B20-SS-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B20-SS-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B40-A-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B40-A-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B40-A-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B40-SS-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B40-SS-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-1B40-SS-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B20-A-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B20-A-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B20-A-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B20-SS-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B20-SS-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B20-SS-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B40-A-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B40-A-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B40-A-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B40-SS-H12 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B40-SS-H19 | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
| ZPS20-2B40-SS-S | -65 [kPa] | 174 [l/min] | 283 [l/min] | |
Installation size: ZPS30 | ||||
| Order-No. | Max. vacuum level | Volume flow | Air consumption at 4 bar | |
| ZPS30-1B20-A-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B20-A-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B20-A-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B20-SS-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B20-SS-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B20-SS-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B40-A-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B40-A-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B40-A-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B40-SS-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B40-SS-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-1B40-SS-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B20-A-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B20-A-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B20-A-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B20-SS-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B20-SS-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B20-SS-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B40-A-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B40-A-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B40-A-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B40-SS-H12 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B40-SS-H19 | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
| ZPS30-2B40-SS-S | -87 [kPa] | 171 [l/min] | 350 [l/min] | |
