SPN Zero-Point Clamping System
Series Standard
"The economical"
- Concentration on the basic functions
- Locking by means of clamping segments
- PLUS connection
- Rustproof – tempered stainless steel
- Two integrated rotation locks
- Optional automatic seal
Installation Size: SPN062SD
| Order-No. | Holding force max. | Operating pressure | Pull-in force | |
|---|---|---|---|---|
| SPN062E6SD-B | M8 | 6 ... 7 [bar] | 2 [kN] | |
| SPN062E4SD-B | M8 | 4 ... 7 [bar] | 1 [kN] |
Installation Size: SPN112SD
| Order-No. | Holding force max. | Operating pressure | Pull-in force | |
|---|---|---|---|---|
| SPN112E6SD-B | M10/M12 | 6 ... 7 [bar] | 6 [kN] | |
| SPN112E4SD-B | M10/M12 | 4 ... 7 [bar] | 4 [kN] |
Installation Size: SPN138SD
| Order-No. | Holding force max. | Operating pressure | Pull-in force | |
|---|---|---|---|---|
| SPN138E6SD-B | M12/M16 | 18 [kN] | ||
| SPN138E4SD-B | M12/M16 | 12 [kN] |
- Housing
- Clamping pin
- Cover
- Clamp dog
- Clamping segments
- Spring package
- Torque support/rotation lock
Reddot Design Award 2019
IF Design Award 2019
