Actuation by cheese head screw

New

Avoidance of interfering contours due to the lever
Protection against unintentional release
Cheese head screw instead of clamping lever
Shorter design

Clamping element

Profile rail guide

Theoretical holding force (µ=0,1)

Tightening torque

3.00 Nm - 22.00 Nm

0.066 kg - 2.6 kg

Clamping element

1200 N - 2000 N

Theoretical holding force (µ=0,1)

1500 N - 2500 N

Theoretical holding torque (µ=0,1)

Tightening torque

5.00 Nm - 22.00 Nm

0.23 kg - 3.6 kg

If there is not enough space or access is restricted, the clamping lever can be replaced by a cylinder head screw to open and close the clamping element.
At the same time, the screw ensures a smaller interfering contour and prevents unintentional loosening.
