LWR50L-26-00001-A

Magnetic gripper
Series LWR

Secure hold during EMERGENCY STOP
Magnets attached to springs ensure your workpiece remains secure, even during a drop in pressure
Contact plate that increases friction value
The replaceable O-ring ensures the high dynamics in your application and protection of your workpiece
Residual holding force < 1N
The demagnetised contact surface safeguards the process reliability of dropping off your workpiece

Operating temperature	5 ... +80 [°C]
Certifications	LABS / REACH / RoHS
Protection to IEC 60529	IP40
Weight	0.44 [kg]
Electrical energy transfer	integrated
Locking stroke	1 [mm]
Repetition accuracy in X, Y	0,05 [mm]
Repetition accuracy in Z	0,05 [mm]
Tightening force	50 [N]
Offset at coupling max. in X,Y	1 [mm]
Suitable for series	LWR50F
Adhesive force max.	27 [N]
Operating pressure min.	3 [bar]
Operating pressure max.	8 [bar]
Air volume per cycle	3.5 [cm³]
