Stainless steel version
New
- Stainless steel version
- Use of special greases
Customizable series
Clamping element
Series HK
Profile rail guide
Holding force
130 N - 2000 N
Theoretical holding force (µ=0,1)
163 N - 2500 N
Tightening torque
3.00 Nm - 22.00 Nm
Weight
0.066 kg - 2.6 kg
Clamping element
Series HKR
Round bar
Holding force
1200 N - 2000 N
Theoretical holding force (µ=0,1)
1500 N - 2500 N
Holding torque
7 Nm - 60 Nm
Theoretical holding torque (µ=0,1)
9 N - 75 N
Tightening torque
5.00 Nm - 22.00 Nm
Weight
0.23 kg - 3.6 kg
Clamping element
Series MK
Profile rail guide
Holding force
350 N - 2250 N
Theoretical holding force (µ=0,1)
438 N - 2813 N
Operating pressure
2 bar - 6.5 bar
Weight
0.2 kg - 2.8 kg
Clean room class
6
Clamping element
Series MKS
Profile rail guide
Holding force
145 N - 1450 N
Theoretical holding force (µ=0,1)
313 N - 1813 N
Operating pressure
4 bar - 6.5 bar
Weight
0.21 kg - 3.2 kg
Clean room class
6
Clamping element
Series MKR
Round bar
Holding force
650 N - 1850 N
Theoretical holding force (µ=0,1)
813 N - 2313 N
Holding torque
4 Nm - 56 Nm
Theoretical holding torque (µ=0,1)
5 N - 70 N
Operating pressure
2 bar - 6.5 bar
Weight
0.28 kg - 2.5 kg
Clamping element
Series MKRS
Round bar
Holding force
300 N - 1650 N
Theoretical holding force (µ=0,1)
375 N - 2063 N
Holding torque
1 Nm - 49 Nm
Theoretical holding torque (µ=0,1)
3 N - 61 N
Operating pressure
4 bar - 6.5 bar
Weight
0.3 kg - 2.7 kg
Application description
- By using stainless steel for all components that are exposed to external influences, clamping elements can also be used in areas with special hygiene or cleaning requirements.
- Cleanroom certification extends the range of applications accordingly.
