Lever extension

New

Avoidance of interfering contours thanks to the extended lever
Simple integration into existing designs
Standardized extensions in 25/50/100/150/200mm

Clamping element

Profile rail guide

Theoretical holding force (µ=0,1)

Tightening torque

3.00 Nm - 22.00 Nm

0.066 kg - 2.6 kg

Clamping element

1200 N - 2000 N

Theoretical holding force (µ=0,1)

1500 N - 2500 N

Theoretical holding torque (µ=0,1)

Tightening torque

5.00 Nm - 22.00 Nm

0.23 kg - 3.6 kg

If space is limited, the clamping lever can be mounted on the outside using an extension.
This ensures better accessibility.
