Initiator query
New
- Integration of a sensor for status monitoring
Customizable series
Clamping element
Series MK
Profile rail guide
Holding force
350 N - 2250 N
Theoretical holding force (µ=0,1)
438 N - 2813 N
Operating pressure
2 bar - 6.5 bar
Weight
0.2 kg - 2.8 kg
Clean room class
6
Clamping element
Series MKS
Profile rail guide
Holding force
145 N - 1450 N
Theoretical holding force (µ=0,1)
313 N - 1813 N
Operating pressure
4 bar - 6.5 bar
Weight
0.21 kg - 3.2 kg
Clean room class
6
Clamping element
Series MKR
Round bar
Holding force
650 N - 1850 N
Theoretical holding force (µ=0,1)
813 N - 2313 N
Holding torque
4 Nm - 56 Nm
Theoretical holding torque (µ=0,1)
5 N - 70 N
Operating pressure
2 bar - 6.5 bar
Weight
0.28 kg - 2.5 kg
Clamping element
Series MKRS
Round bar
Holding force
300 N - 1650 N
Theoretical holding force (µ=0,1)
375 N - 2063 N
Holding torque
1 Nm - 49 Nm
Theoretical holding torque (µ=0,1)
3 N - 61 N
Operating pressure
4 bar - 6.5 bar
Weight
0.3 kg - 2.7 kg
Clamping element
Series UBPS
Profile rail guide
Holding force
750 N - 7700 N
Theoretical holding force (µ=0,1)
1250 N - 9625 N
Operating pressure
4 bar - 6.5 bar
Weight
0.9 kg - 15 kg
Clamping element
Series MBPS
Profile rail guide
Holding force
750 N - 4700 N
Theoretical holding force (µ=0,1)
938 N - 5875 N
Operating pressure
4.5 bar - 6.5 bar
Weight
0.42 kg - 3.9 kg
Application description
- The status of the clamping and braking element can be reliably monitored using the integrated initiator, which increases machine safety.
- Process chains can be accelerated as no waiting time is required and work can continue as soon as the sensor signal is received.
