BCM-B-01-00-A
Bridge Communication Module
Series BCM
- All Zimmer Group IO-Link components can be used, regardless of the structure of the existing robot / system base
- No complex cable routing through the robot or system (slip rings, contact elements etc. not required)
- No source of error due to moving data cable (mechanical obstacle, broken wire) wearing part eliminated
- Wireless range of point-to-point communication up to 10 m, up to 30 m with unobstructed view
- Scalable, simple expansion of further grippers by logging on to the master
- Industrial design
- IP67 certified
Technical Data
| Control | IO-Link wireless |
| Number of grippers, max. | 1 |
| IO-Link class | Class A/B |
| IO-Link version | 1.1 |
| Frequency range | 2.4 [GHz] |
| Antenna | Intern Isotrop |
| Supply voltage | 18 ... 32 [V DC] |
| Continuous current load supply | 4 [A] |
| Load supply peak current | 5 [A] |
| Supported transmission protocol | COM 3 |
| Mounting options | Screw mounting with clip, Free |
| Operating temperature | -25 ... +50 [°C] |
| Certifications | CE / UKCA / LABS / REACH / RoHS |
| Protection to IEC 60529 | IP67 |
| Weight | 38 [g] |
Certificates
Canada-ISED-TigoBridge-B1-CT231-0057-01
EU-ETSI-CE-TigoBridge-B1-CT231-0057-01
FCC-TigoBridge-B1-CT231-0057-01
TigoBridge-B1-Certificate-of-Compliance-Reach
TigoBridge-B1-Certificate-of-Compliance-RoHS
UL-TigoBridge-B1-CT231-0057-01
